Comparison of CT Imaging Methods for Defect Detection in a Multi-Material 7-Pin Power Connector Article Swipe

PDF

Jochen Butzer , Thomas Riedel , C. Woelk , Uta Proettel , André Döring , Philipp Kurth , Fabian Rückert , Darius Rückert ·

YOU? · · 2025 · Open Access · · DOI: https://doi.org/10.58286/31459

This paper explores industrial computed tomography (CT) for detection of anomalies such as voids and gaps in power connectors for automotive application. Such defects can lead to leakage paths which can cause electrical malfunction or short circuits. A primary challenge in CT analysis arises from the proximity of dense metal parts next to plastic material, which induces strong imaging artifacts that hinder the evaluation of such defects. This study evaluates three imaging methods - standard Filtered Back Projection reconstruction (FBP), Quantum Reconstruction Technique (QRT), and dual-energy combination (DE) - to mitigate these artifacts and improve defect visualization. Each method's efficacy is assessed by analyzing the accuracy in detecting and characterizing gaps and voids. Results are compared to a target preparation and cross-section analysis with optical microscopy, providing a benchmark for reliability and accuracy. Full experimental findings and comparisons are detailed in the complete paper.
